   Storage

信维提供多样化的 RAID 存储,高存储密度。低延迟SSD应用程序,需要庞大容量的大型媒体文件和寻求最高性能的企业工作负载将受益于信维的SAS 3.0(12Gbps)支持,可提供低延迟和最大数据带宽。 信维Storage系统提供了一个不折不扣的存储平台,具有使用2.5“或3.5”SSD / HDD的2U、3U和4U外形尺寸的灵活的市场入口点。 信维Storage服务器支持:1TB 3DS ECC LRDIMM或256GB ECC RDIMM内存,PCI-E 3.0插槽,NVMe,灵活的网络选项,如10G SFP +,10GBase-T LAN端口和IPMI 2.0以及带有专用LAN的KVM,并支持最新的英特尔® 至强®可扩展处理器。
信维Storage特点:
● 完整的产品组合 - 针对Microsoft,VMWare和软件定义储存解决方案优化的完整的开放行业标准储存产品组合
● 最大性能 - 完全NVMe支持,混合扩展器和直接连接储存底板
● 最大效率 - 具有行业领先密度的大容量2U、3U和4U外壳。 最高效率的铂金电源(95%功率效率)
● 可靠性 - 完全备用、容错架构、带热插入驱动器托架、电源和冷却风扇。具有主动功能的JBOD硬件非常适合任务关键型应用
型号 | 内存 | CPU | 电源 | 硬盘 |
SW G220-G4I | 16x DDR4 DIMM slot | 双路 | 550W Platinum,1+1 redundancy | 12x 3.5 |
SW R400-60Q | - | - | (2) 1400W high efficiency redundant PSUs | 60 x 2.5"or 3.5" |
SW R222-G70I | 16x DDR4 DIMM slot | 双路 | 1400W Platinum;2+2 redundancy | 70x 3.5” |
SW R420-G36A | 16x DIMM slot | 单路 | 800W | 36 x 3.5”+2x2.5 |
SW R400-024Q | - | - | 500W Redundant Power Supply, 100-240VAC, Platinum | 24 x 3.5 |
SW R400-060Q | - | - | (2)1400W 220VAC or (2)1200W 100-220VAC PSUs | 60 x 2.5 |
SW R400-24Q | - | - | (2)760W redundant power | 24 x 2.5 |
SW R420-G102Q | 16x DIMM slot | 双路 | 1600W | 102x 3.5 |
SW R420-G70Q | Wellsburg PCH RSTe | 双路 | 1200W | 70x 3.5 |
SW R120-D04Q | 4x DIMM slot | 单路 | 400W | 12x3.5 |
SW R120-G12Q | 16 DIMM slots | 双路 | 700W | 12 x 3.5’' |
SW R420-G70I | 16x DIMM slot | 双路 | 1200W 白金版电源,2+2 冗余 | 12 x 3.5 |
SW R220-R12 | 16 DIMM slots | 双路 | 1+1 Redundant PSU, 460W | 12 x 3.5”HDD |
SW R120-G12R | 16x DIMM slot | 双路 | Fixed PSU (600W) | 12 x 3.5” HDD |
SW R220-G24I | 16x DDR4 slot | 双路 | 550W Platinum; 1+1 redundancy | 12x 3.5”or 24x 2.5” |
SW R422-R70I | 16x DIMM slot, DDR3 | 双路 | 1200W | 70x 3.5” |
SW R402-70I | - | - | 1400W Platinum,2+1 redundancy | 70x 3.5” |
SW R222-G24I | 16 DIMM slots | 双路 | 1400W; 1+1 AC redundant PSU | 12x LFF/24x SFF SAS/SATA |
SW R220-P12C | 4 DDR4 SODIMM | 双路 | 800W | 12 x 3.5” or 24 x 2.5” |
SW R400-060C | - | - | 1200W, 80 plus gold, 1+1 redundant | 60 x 2.5” |
SW R220-G12R | 16 DIMM slots | 双路 | 800W*2(1+0,1+1 冗余) | 12 x 3.5’' |
SW R300-80I | - | - | 1600W Platinum; 2+2 redundancy | - |
SW R120-R12Q | 8x DIMM slot | 单路 | 2x450W Redundant PSUs, 80plus Gold | 12x3.5 |
SW R110-G12R | 4x DIMM slot | 单路 | Fixed PSU 500W or 600W | 12 x 3.5” HDD + 2 x 2.5” |
SW R220-R12I | 24 DIMM slots | 双路 | 1+0 Redundant PSU, 460w | 12 x 3.5’'HDD |
|
|
名 称: SW R300-80I
处理器: -
简 介:● First Flash-based Storage Product in 19” Rack
● High Density and Capacity
● Qualified by Super 7 CSPs |
|
|
|
|
名 称: SW R400-60Q
处理器: -
简 介:High Performance High Density 4U Disk Expansion Unit
● Four 12Gb SAS Host Interfaces
● High Reliability, Serviceability and Availability
● Full Redundancy with No Single-Point-of-Failure
● Cost-effectiveness Shared Architecture |
|
|
|
|
名 称: SW R400-060C
处理器: -
简 介:SW R400-060C is a storage enclosure product based on SAS 12G technologies. It is a high
density bulk storage system, housing two Expansion Storage Modules (ESMs) in one
4U chassis. Rainbow supports up to 60 3.5” or 2.5” SAS drives, including SSDs and
HDDs, with excellent performance and high availability. |
|
|
|
|
名 称: SW R402-70I
处理器: 英特尔® 至强® 处理器 E5-2600 产品系列
简 介: • Full hardware redundancy with SAS
12G RAID, redundant power and dual
SIM node.
• Ultra dense storage expansion with
equivalent density of 17.5 drives per
1RU.
• Supporting 1-70, 35-35 and 70-70
multi HDD control modes. |
|
|
|
|
|
|
|
|
